LUXOR UV-A3 DTF PRINTER

MULTI-FUNCTION DESIGN SUPPORTING 4 APPLICATIONS - Flatbed, Cylinder, Roll-to-roll, and UV DTF all in one machine. Production speed 0.28-3 m²/h ideal for high quality, cost-efficient production.

Contact Sales

A3Print Format

0.28-3 m²/hPrint Speed

4-in-1Multi-function

Product Overview

The LUXOR UV-A3 DTF Printer offers flatbed, cylinder, roll-to-roll, and UV DTF printing in one compact unit, ideal for high quality, cost-efficient production. Featuring advanced technology with production speeds ranging from 0.28-3 m²/h, this versatile machine delivers exceptional results for diverse printing applications.

Click to view fullscreen

Key Features

Advanced UV-A3 multi-function printing technology meets professional performance

Silent Ink Chain

Zero splashing and low noise operation ensures quiet and clean printing environment for professional workspace.

Intelligent Ink Supply

Advanced ink supply system with smart monitoring ensures consistent ink flow and optimal color reproduction.

HD Touch Screen Design

User-friendly HD touch interface for easy operation control and real-time monitoring of printing status.

High-Quality Printing

Superior print quality with excellent color reproduction and fine detail resolution for professional results.

4-in-1 Multi-Function Design

Versatile machine supporting flatbed, cylinder, roll-to-roll, and UV DTF printing in one compact unit.

Variable Production Speed

Flexible production speed from 0.28-3 m²/h to meet different quality and volume requirements.

Technical Specifications

Complete technical details for LUXOR UV-A3 DTF Printer

Machine Specifications

Model

UV-A3

Printhead Quantity

Printhead Type

EPSON I3200(4) UV HD Printhead

Print Speed

0.28 m²/h - 3 m²/h

Printhead Cleaning

Automatic Cleaning, Automatic Flush Spray, Moisturizing Function

Ink Color

C+M+Y+K+W+Varnish, Magenta+White

Ink Type

LED UV Curing Ink

Printing Media Type

Ultra-clear PET Film, Back-lit Film, PET, Transparent Film, Canvas, Velvet Cloth, etc.

Print Media Thickness

Type: 0.8mm

RIP Software

Maintop, FlexiPRINT, Gln, etc.

Image Format

JPG, TIF, BMP, PDF, etc.

Working Environment

Temperature: 10°C-30°C, Humidity: 35%-65%

Print Width

Flatbed: A3(White+Color)|UV DTF: 33cm+|Cylinder: 35×40cm+(Diameter≥7)

Machine Dimension

990*650*785mm|UV DTF Assembly: 775*600*350mm|Packing: 1400*950mm

Weight

NetWeight: 200KG|GrossWeight: 220KG|UV DTF Assembly Net Weight: 50KG|Gross Weight: 70KG

Applications

Professional UV-A3 multi-function printing solutions for diverse applications

Phone Case

Frames or Panels

Decorative Items

Tumbler

Personalized Gifts

Customized Jar

Phone Case

Frames or Panels

Decorative Items

Tumbler

Personalized Gifts

Customized Jar

Phone Case

Frames or Panels

Decorative Items

Tumbler

Personalized Gifts

Customized Jar

Why Choose LUXOR UV-A3?

EPSON I3200 UV HD printhead for exceptional print quality

Multi-function 4-in-1 design: Flatbed, Cylinder, Roll-to-roll, UV DTF

Variable speed production from 0.28-3 m²/h for different needs

LED UV curing ink system for instant drying and durability

Automatic printhead cleaning and moisturizing function

HD touch screen interface for user-friendly operation

Silent ink chain technology for quiet operation

Wide media compatibility: PET film, canvas, velvet cloth, etc.

Professional A3 format printing capability

Multiple RIP software support (Maintop, FlexiPRINT, Gln)

Compact design suitable for various workspace environments

Cost-efficient production with high-quality output
